Details:
The machine is used for rinsing glass and plastic bottle by compressed air, which enters into the bottle, rinses the internal of bottle and then is absorbed out from another exit. Since the machine is fully closed, the powder, dust, water drops or impurities in bottle or on the wall of bottle can be blown away. The development and manufacture of the equipment fills in the gap in the market. With continuous improvement for several years, this kind of equipment has been launched in mass and obtained above 90% of domestic market shares.
Features of air washing machine for bottles:
1) Simple structure, stable function, easy operation and low maintenance cost.
2) Automatic bottle in and out, cylinder damper control.
3) Be convenient to exchange specification, and just to adjust the height of needle and the distance of cylinder damper.
4) PLC control and man-machine control for bottle washing process.
5) Effectively clean up contaminates such as dust and carton chip.
6) Contaminates is draw out from vacuum pipe, no circulate and no pollution.
7) Constructed of stainless steel 304, smooth surface, easy unpick and wash.
8) Washing quality satisfied the GMP regulation.
Technical Parameter on air cleaner machine:
Scope of bottle: 20-500ml Production capacity: 5000bpm
Air pressure range: 6-8kg/cm Air consumption: 25m3 /h
Power supply: 220V 50/60Hz Power consumption: 0.75Kw
Single machine noise: ≤70dB Purified air: 0.2 micron
Cleaning time: 3-5 seconds Net weight: 500Kg
Overall dimension (mm): 1200(L)×800(W)×1600(H)
For more information about our automatic linear air washing machine for plastic pet or glass bottle cleaning process,browse our business blogger http://cosmeticfoodmakingpackaging.blogspot.com or directly send us by email for furthur learning jackdu999@yahoo.com .
Scope of bottle: 20-500ml Production capacity: 5000bpm
Air pressure range: 6-8kg/cm Air consumption: 25m3 /h
Power supply: 220V 50/60Hz Power consumption: 0.75Kw
Single machine noise: ≤70dB Purified air: 0.2 micron
Cleaning time: 3-5 seconds Net weight: 500Kg
Overall dimension (mm): 1200(L)×800(W)×1600(H)
For more information about our automatic linear air washing machine for plastic pet or glass bottle cleaning process,browse our business blogger http://cosmeticfoodmakingpackaging.blogspot.com or directly send us by email for furthur learning jackdu999@yahoo.com .
