carton sealing machine show-how of carton sealer case sealing equipment Kartonverschlussmaschine

carton sealing machine show-how of carton sealer case sealing equipment Kartonverschlussmaschine
Interchangeable top bottom Dispenser
Tape Overlap length can be adjusted
Blade Guards Leg height Adjustable
Coding Optional

Application of carton sealer
Very fast sealing of Boxes.
Top & Bottom side in one Operation.
Food, Pharmaceuticals, Pesticides etc.
Technical Specifications
Sr No. Model S - 22

1Conveyor Speed 18 mtr./min.
2Max. Box Size (W) 500 mm x (H) 500 mm
3Min. Box Size (W) 100 mm x ( H) 100 mm
4Power Supply Single Phase
5Power Consumption 240 W
6Belt Drive Side Drive
7Width of Tape 1", 1.5", 2.5", 3"
8Machine Size (1620 x 790 x 1500) mm
9Machine Weight 120 Kg.
For more information about YX series carton sealing machine,feel free to send us the email jackdu999@yahoo.com or browse our business blogger www.cosmeticfoodmakingpackaging.blogspot­.com.

PENGLAI INDUSTRIAL CORPORATION LIMITED

fully automatic flaps folding carton sealer Full auto case sealing machine auto box sealing machine

fully automatic flaps folding carton sealer Full auto case sealing machine auto box sealing machine.
The top is automatically folded,Automatic feed in time, without man-care,available to conncect to full automatic production line
YX-5050Automatic flaps folding carton sealer(auto carton sealer,carton sealing machine)

Product Description:
Interchangeable top bottom tape cartridge;
2" Top and Bottom Tape Head
Adjustment to various cartons size;
The top is automatically folded;
Automatic feed in time, without man-care,available to conncect to full automatic production line.

Leg height adjustment 350 mm;
Infeed/Outfeed Tables and 3" Tape Head are optionnal;
Optional casters locking/swivel
Specification:
Model YX-5050
Voltage(V/Hz) AC 220/50 110/60 Power(W)260
Max. Carton Size(W×H×L)(mm) 500×500×600
Min. Carton Size (W×H×L)(mm) 130×130×180
Speed(m/min) 22
Width of Adhesive Tape(mm) 48 60 76
Air Compressor 2/3 Litres at 5 bars
Dimension (L×W×H)(mm) 2720×950×(1200-1800)
Net Weight(kg) 180

The top is automatically folded,Automatic feed in time, without man-care,available to conncect to full automatic production line.
fully automatic flaps folding carton sealer Full auto case sealing machine auto box sealing machine mofe information directly send us email jackdu999@yahoo.com or browse business youtubehttp://youtube.com/user/mrjackdu007

PENGLAI INDUTRIAL CORPORATION LIMITED

semi automatic four sides carton sealing machine Selladora de cajas de cartón

semi automatic four sides carton sealing machine Selladora de cajas de cartón in the case or carton packaging industry.
Semi-Automatic Carton Sealers are useful for lower speed production lines where the packer has time to load the carton with product, fold the flaps, and push the carton into the carton sealer. Generally speaking if a second person is required to keep up with production, it is time to think about an Automatic Carton sealer.

The big difference between an Automatic Carton Sealer and a Semi-Automatic Carton Sealer is the addition of the flap folding mechanism and the added length to accommodate it. When the carton enters the carton sealer the forward flap is knocked down, the mechanism then knocks down the trailing flap, and finally the side flaps are folded by folding bars.

For more information about PENGLAI carton sealing machine in various models ,welcome to browse our business youtubehttp://youtube.com/user/mrjackdu007 or directly send us email jackdu999@yahoo.com business sitehttp://youtube.com/user/mrjackdu007

PENGLAI INDUSTRIAL CORPORATION LIMITED
